HM10 Series Hydraulic Divider Control Valve For Bulldozers

 HM10 Series Hydraulic Divider Control Valve For Bulldozers



The HM10 Series Hydraulic Divider Control Valve is a core hydraulic control component specially designed for bulldozers. Its core value lies in ensuring that bulldozers perform complex operations such as pushing earth, leveling land, and loosening soil through precise hydraulic distribution and pressure regulation. Each actuator (such as bulldozers and soil looseners) can obtain stable and matched hydraulic power. Whether it is a heavy-duty crawler bulldozer or a medium-sized wheeled bulldozer, this valve can be adapted to the characteristics of their hydraulic systems and become a key support for improving operational efficiency.



As a representative product of the hm10 hydraulic valve series, it adopts an integrated diversion structure design - when the hydraulic oil enters the valve from the main oil circuit, it will be diverted to different actuating components in the preset proportion through the coordinated operation of the internal precision valve core, avoiding operation jamming caused by uneven power distribution. Meanwhile, the wear-resistant sealing components of hm10 hydraulic valve have undergone special process treatment, which can withstand the common high-pressure and dusty environment in bulldozer operations, significantly reducing the risk of oil leakage and extending the equipment maintenance cycle.

As a professional hydraulic divider valve, its diversion accuracy can reach ±2%, and it can precisely respond to operation instructions: When the bulldozer needs to complete the actions of pushing earth and turning simultaneously, the valve can quickly adjust the flow and pressure of the two hydraulic oil lines to ensure the stable force of the bulldozer while the turning action is flexible and without delay. This precise diversion ability is precisely the core advantage of hydraulic divider valve that distinguishes it from ordinary control valves, and it is also the key to ensuring the continuity of complex operations of bulldozers.



The HM10 Series Hydraulic Divider Control Valve is compatible with the hydraulic system interfaces of mainstream brand bulldozers. No additional modification is required during installation and it can be quickly integrated into the original hydraulic circuit of the equipment. Its shell is made of high-strength cast iron, which has excellent impact resistance. Even in the frequent bumpy operation scenarios of bulldozers, it can still maintain structural stability.

Furthermore, the modular design of the hm10 hydraulic valve makes later maintenance more convenient - if the vulnerable parts need to be replaced, the corresponding modules can be directly disassembled without disassembling the valve as a whole, significantly reducing the downtime. As the hydraulic divider valve with verified reliability, it can work stably within the temperature range of -20 ℃ to 80℃, adapt to extreme working conditions such as severe cold and high temperature, and become the "reliable partner" of bulldozers in various construction environments.



The HM10 Series Hydraulic Divider Control Valve, with its precise diversion control, strong environmental adaptability, and high compatibility with bulldozers, has become the "control hub" in the hydraulic system. Whether it is the engineering team pursuing operational efficiency or the operation and maintenance personnel focusing on equipment durability, this product that integrates the technical essence of hm10 hydraulic valve and the core functions of hydraulic divider valve can meet the demands and provide a solid guarantee for the stable and efficient operation of bulldozers.





HM10 series integral valve introduced the European advanced technology, with compact structure, flow rate up to 120l/min, light weight. The valve uses parallel oil circuit, designed with a pressure outlet and other hydraulic components connected to provide power source. The valve is widely used in construction machinery, sanitation machinery, mining machinery and other machinery hydraulic system.





1 Simple, compact designed, this valves is only one section for open centre and closed centre hydraulic systems.

2 Fitted with a main pressure relief valve.

3 Diameter 20 mm -- 0.79 in interchangeable spools.

4 Available manual, pneumatic, electro--hydraulic and remote with flexible cable spool control kits.





Nom.Pressure (MPa)	Max.Pressure (MPa)	Nom.Flow rate (L/min)	Max.Flow rate (L/min)	Back Pressure (MPa)	Hydraulic Oil
					Tem.rang (℃)	Visc.rang (mm2/S)	Filtrating Accuracy (μm)
20	25	120	120	≤1	-20～+80	10～400	≤10
